TredLok
Solid, interlocking checker-plate PVC tiles designed for garages, locker rooms, fitness areas and workshops
Perfect for protecting any type of floor and designed to absorb shock and noise. TredLok™ is fully wheelchair, baby stroller and shopping cart compatible.
Its solid surface provides a seamless floor covering, while the non-porous PVC remains resistant to chemicals, oils, acids and extreme temperatures. A hard-wearing coin patterned surface delivers excellent slip resistance, alongside shock and noise absorption properties. Ideal for work stations, garages, storage areas, gym and fitness centres, and anywhere where temporary floor protect might be needed.
Flexible format
Comes in 18" x 18" tiles with a height of 9'6"
Flexible format
Comes in 18" x 18" tiles with a height of 9'6"
Simple installation
PVC interlocking tiles that easily and securely lock into place
Easy to maintain
Simply lift to clean, no special tools needed
Simple installation
PVC interlocking tiles that easily and securely lock into place
Easy to maintain
Simply lift to clean, no special tools needed
Features
3 bar checker-plate pattern
Made from non-porous PVC
Interlocking jigsaw tiles with PVC ramped edging
Made from 100% recycled material (black only)
Excellent sound absorption properties
Benefits
Slip resistant
Resistant to chemicals, acids, oils
Seamless installation
100% recyclable after use
Reduces noise levels
| TredLok | |
| Height | 7/16" (11mm) |
| Standard tile size | 18.5" x 18.5" (0.47m x 0.47m) |
| Weight | 1.40 lb/sq.ft (6.8 kg/m2) |
| Acoustic | Excellent sound absorption |
| Batch control | We are unable to guarantee 100% color consistency between individual production batches. Each individual order will be supplied from a single batch, but in the event that you need additional tiles, or wish to extend the area we cannot guarantee subsequent orders will be supplied from the same batch. |
| Chemical | The polymeric structure of PVC is resistant to most oils and acids. You can read more about specific chemical resistances by downloading this information sheet. |
| Composition | Flexible Polyvinyl Chloride (PVC) |
| Environment | TredLok when made in black is 100% recyclable and manufactured from waste materials that would otherwise have gone to landfill. |
| Fire | BFL-S1 |
| Rolling load | ASTM F2753 Rolling load over resilient floor covering |
| Reversion | Thermoplastic shrinkage can result in size reductions up to 2%. This may be accelerated in hot environments. You can read more about the causes of shrinkage by downloading this information sheet. |
| Slip resistance | ASTM E303: 82/59 |
| Staining | Rubber tyres may stain the light colored tiles. This is a result of a chemical reaction that occurs between the antioxidant that is used in some rubbers and the plasticizer used in vinyl. We recommend choosing our black or grey tiles if your application could be subject to staining. You could also consider the application of an anti-stain or varnish to avoid any staining to the tiles. |
| Thermal | Designed to function at temperatures from -7°F and up to +140°F. Slight size variation may occur at temperature extremes. |
| UV light | TredLok tiles (black only) are made from 100% recycled PVC material. We cannot determine the UV stability however PVC has good natural properties to cope with outdoor environments. We shall not be held responsible for any defects that may or may not occur. Our colored tiles can be manufactured in a UV stable compound please enquire for a specific quote if this specification is required. |
| Warranty | Three years. Warranted to be free from any defects in materials and workmanship. The buyer shall determine the suitability of the products for its intended use, and shall not rely upon any representations made by or on behalf of TechPlas Inc. |
| Weight load (static) | 7385 lbs (3.35 tonnes) |
TredLok edging (male)
Supplied in 1'8" (50cm) lengths. Comes in black and yellow. Size: 1/2" x 2" x 1'8" (12mm x 50mm x 500mm)
TredLok edging (female)
Supplied in 1'8" (50cm) lengths. Comes in black and yellow. Size: 1/2" x 2" x 1'8" (12mm x 50mm x 500mm)
TredLok's interlocking system means installation is simple
- Tiles easily and securely lock into place
- Effectively covers large areas
- No special tools needed
Keeping TredLok looking good is easy
- Light to handle
- Simply lift to clean
- Easy to clean with a high pressure hose
Features
3 bar checker-plate pattern
Made from non-porous PVC
Interlocking jigsaw tiles with PVC ramped edging
Made from 100% recycled material (black only)
Excellent sound absorption properties
Benefits
Slip resistant
Resistant to chemicals, acids, oils
Seamless installation
100% recyclable after use
Reduces noise levels
| TredLok | |
| Height | 7/16" (11mm) |
| Standard tile size | 18.5" x 18.5" (0.47m x 0.47m) |
| Weight | 1.40 lb/sq.ft (6.8 kg/m2) |
| Acoustic | Excellent sound absorption |
| Batch control | We are unable to guarantee 100% color consistency between individual production batches. Each individual order will be supplied from a single batch, but in the event that you need additional tiles, or wish to extend the area we cannot guarantee subsequent orders will be supplied from the same batch. |
| Chemical | The polymeric structure of PVC is resistant to most oils and acids. You can read more about specific chemical resistances by downloading this information sheet. |
| Composition | Flexible Polyvinyl Chloride (PVC) |
| Environment | TredLok when made in black is 100% recyclable and manufactured from waste materials that would otherwise have gone to landfill. |
| Fire | BFL-S1 |
| Rolling load | ASTM F2753 Rolling load over resilient floor covering |
| Reversion | Thermoplastic shrinkage can result in size reductions up to 2%. This may be accelerated in hot environments. You can read more about the causes of shrinkage by downloading this information sheet. |
| Slip resistance | ASTM E303: 82/59 |
| Staining | Rubber tyres may stain the light colored tiles. This is a result of a chemical reaction that occurs between the antioxidant that is used in some rubbers and the plasticizer used in vinyl. We recommend choosing our black or grey tiles if your application could be subject to staining. You could also consider the application of an anti-stain or varnish to avoid any staining to the tiles. |
| Thermal | Designed to function at temperatures from -7°F and up to +140°F. Slight size variation may occur at temperature extremes. |
| UV light | TredLok tiles (black only) are made from 100% recycled PVC material. We cannot determine the UV stability however PVC has good natural properties to cope with outdoor environments. We shall not be held responsible for any defects that may or may not occur. Our colored tiles can be manufactured in a UV stable compound please enquire for a specific quote if this specification is required. |
| Warranty | Three years. Warranted to be free from any defects in materials and workmanship. The buyer shall determine the suitability of the products for its intended use, and shall not rely upon any representations made by or on behalf of TechPlas Inc. |
| Weight load (static) | 7385 lbs (3.35 tonnes) |
TredLok edging (male)
Supplied in 1'8" (50cm) lengths. Comes in black and yellow. Size: 1/2" x 2" x 1'8" (12mm x 50mm x 500mm)
TredLok edging (female)
Supplied in 1'8" (50cm) lengths. Comes in black and yellow. Size: 1/2" x 2" x 1'8" (12mm x 50mm x 500mm)
TredLok's interlocking system means installation is simple
- Tiles easily and securely lock into place
- Effectively covers large areas
- No special tools needed
Keeping TredLok looking good is easy
- Light to handle
- Simply lift to clean
- Easy to clean with a high pressure hose
