Gateway Walk
A one-piece entrance mat designed for longer walkways and narrower entrances, both indoors and out.
This one-piece entrance system is the ideal slip-resistant entrance solution for narrower building entrances and longer walkways.
Designed for both internal and external use, Gateway Walk features a diamond-cut pattern and cross-directional top ribs to ensure a firm grip underfoot, while simultaneously scraping wheels and shoes clean.
Heel-proof and wheel-proof with excellent rolling resistance, this durable mat can be loose laid for a roll-and-go slip resistant solution or installed as a surface-mounted entrance mat.
The one-piece construction means the mat can be quickly rolled out where needed or cut to fit on site – no previous site visits required.
Seamless integration
Comes in 6m (20’) rolls or order a custom size
Simple installation
One-piece construction means the entrance matting can be cut to size on site
Easy to maintain
Simply roll or lift to clean, no special tools needed
Features
Embossed pattern
Two layer, open-grid construction
Close mesh grid
Made from flexible PVC
Comes in 6m (33') rolls or modules
Benefits
Certified slip resistant (DIN 51130: R11)
Excellent drainage (DIN 51130: V10)
Wheel and heel proof
Easy to cut on site, contours to uneven surfaces
Seamless installation
| Gateway Walk | |
| Height | 10mm (3/8”) |
| Standard roll options | 0.91 x 6m (3’ x 20’) |
1.22 x 6m (4’ x 20’) | |
| Weight | 8 kg/m2 (17.7 lbs/sq.ft) |
| Acoustic | Excellent sound absorption. |
| Chemical | Resistant to most acids, alkalines and oils. You can read more about specific chemical resistances by downloading this information sheet. |
| Composition | Flexible Polyvinyl Chloride (PVC) |
| Environment | Gateway Walk is 100% recyclable. We don’t use any substances included in the SVHC list under REACH in any of our matting products. |
| Fire | EN ISO 13501-1:2007-Bfl-S1, ASTM E648, Class 1 |
| Reversion | Thermoplastic shrinkage can result in size reductions up to 2%. This may be accelerated in hot environments. You can read more about the causes of shrinkage by downloading this information sheet. |
| Rolling Resistance | ASTM F 2753: No apparent damage to the vinyl portion of the system after 1,000 cycles at 1000lbs. |
| Slip resistance | DIN 51130: R11, V10 |
| Thermal | Designed to function at temperatures from -23°C and up to +60°C. Slight size variation may occur at temperature extremes. |
| UV light | Resistant to PVC degradation. |
| Volatile organic compound (VOC) | CDPH/EHLB Standard Method V1.2-2017 (California Section 01350) - School Classroom: PASS CDPH/EHLB Standard Method V1.2-2017 (California Section 01350) - Office: PASS Measured concentration of Total Volatile Organic Compounds (TVOC): Less than/equal to 0.5 mg/m³ (in compliance with CDPH.EHLB Standard Method v1.2-2017 |
| Warranty | Four years. Visit our policies page for more information about warranties. |
For surface-mounted installations
PVC edging (H: 10mm, W: 50mm)
Supplied in rolls of 10.1m (33') length with cold welding paste. Comes in black and dark grey. Size: 10mm x 50mm x 10.1m (3/8" x 2" x 33')
Connector clips: side-to-side (H: 10mm)
For joining sections of low profile matting together side-to-side. Supplied in packs of 10
PVC snap track (H: 10.5mm)
Two-part snap track that can be welded together to join rolls end-to-end or side-to-side to cover large areas. Supplied with cold welding paste. Comes in dark grey. Size: 10.5mm x 2.5m (13/32" x 8'2")
For recessed installations
R frame (H: 10mm)
You'll need these to secure the matting on the left-to-right edges. Supplied in sections of 3m (10') length with fixing screws and plugs. Comes in anodised aluminium, powder coated dark grey and black. Size: 10mm x 12mm (3/8" x 15/32")
U section (H: 10mm)
If the front-to-back dimension of the mat well is greater than the final width of your matting, you may need a U section to secure the different sections together. Supplied in sections of 3m (10') length, with fixing screws and plugs. Comes in anodised aluminium, powder coated dark grey and black. Size: 10mm x 18mm (3/8" x 11/16")
Gateway Walk's one-piece construction means installation is simple
- Integrates seamlessly with all internal floor coverings
- Fits with different well depths
- Contours to the floor
- Cut to fit on site – no special tools or previous site visits needed
Watch the videos below for step-by-step installation guides, or download the recessed entrance matting installation instructions and the surface-mounted installation instructions.
Keeping Gateway Walk looking good is easy
- Simply roll or lift to clean
- No special tools needed
- Easy to clean using a vacuum, plus a coarse brush for clearing the debris in the grid
Watch our step-by-step guide to daily, weekly and monthly cleaning below, or download the instructions.
Features
Embossed pattern
Two layer, open-grid construction
Close mesh grid
Made from flexible PVC
Comes in 6m (33') rolls or modules
Benefits
Certified slip resistant (DIN 51130: R11)
Excellent drainage (DIN 51130: V10)
Wheel and heel proof
Easy to cut on site, contours to uneven surfaces
Seamless installation
| Gateway Walk | |
| Height | 10mm (3/8”) |
| Standard roll options | 0.91 x 6m (3’ x 20’) |
1.22 x 6m (4’ x 20’) | |
| Weight | 8 kg/m2 (17.7 lbs/sq.ft) |
| Acoustic | Excellent sound absorption. |
| Chemical | Resistant to most acids, alkalines and oils. You can read more about specific chemical resistances by downloading this information sheet. |
| Composition | Flexible Polyvinyl Chloride (PVC) |
| Environment | Gateway Walk is 100% recyclable. We don’t use any substances included in the SVHC list under REACH in any of our matting products. |
| Fire | EN ISO 13501-1:2007-Bfl-S1, ASTM E648, Class 1 |
| Reversion | Thermoplastic shrinkage can result in size reductions up to 2%. This may be accelerated in hot environments. You can read more about the causes of shrinkage by downloading this information sheet. |
| Rolling Resistance | ASTM F 2753: No apparent damage to the vinyl portion of the system after 1,000 cycles at 1000lbs. |
| Slip resistance | DIN 51130: R11, V10 |
| Thermal | Designed to function at temperatures from -23°C and up to +60°C. Slight size variation may occur at temperature extremes. |
| UV light | Resistant to PVC degradation. |
| Volatile organic compound (VOC) | CDPH/EHLB Standard Method V1.2-2017 (California Section 01350) - School Classroom: PASS CDPH/EHLB Standard Method V1.2-2017 (California Section 01350) - Office: PASS Measured concentration of Total Volatile Organic Compounds (TVOC): Less than/equal to 0.5 mg/m³ (in compliance with CDPH.EHLB Standard Method v1.2-2017 |
| Warranty | Four years. Visit our policies page for more information about warranties. |
For surface-mounted installations
PVC edging (H: 10mm, W: 50mm)
Supplied in rolls of 10.1m (33') length with cold welding paste. Comes in black and dark grey. Size: 10mm x 50mm x 10.1m (3/8" x 2" x 33')
Connector clips: side-to-side (H: 10mm)
For joining sections of low profile matting together side-to-side. Supplied in packs of 10
PVC snap track (H: 10.5mm)
Two-part snap track that can be welded together to join rolls end-to-end or side-to-side to cover large areas. Supplied with cold welding paste. Comes in dark grey. Size: 10.5mm x 2.5m (13/32" x 8'2")
For recessed installations
R frame (H: 10mm)
You'll need these to secure the matting on the left-to-right edges. Supplied in sections of 3m (10') length with fixing screws and plugs. Comes in anodised aluminium, powder coated dark grey and black. Size: 10mm x 12mm (3/8" x 15/32")
U section (H: 10mm)
If the front-to-back dimension of the mat well is greater than the final width of your matting, you may need a U section to secure the different sections together. Supplied in sections of 3m (10') length, with fixing screws and plugs. Comes in anodised aluminium, powder coated dark grey and black. Size: 10mm x 18mm (3/8" x 11/16")
Gateway Walk's one-piece construction means installation is simple
- Integrates seamlessly with all internal floor coverings
- Fits with different well depths
- Contours to the floor
- Cut to fit on site – no special tools or previous site visits needed
Watch the videos below for step-by-step installation guides, or download the recessed entrance matting installation instructions and the surface-mounted installation instructions.
Keeping Gateway Walk looking good is easy
- Simply roll or lift to clean
- No special tools needed
- Easy to clean using a vacuum, plus a coarse brush for clearing the debris in the grid
Watch our step-by-step guide to daily, weekly and monthly cleaning below, or download the instructions.
