Gateway 10
Slip-resistant, open-grid entrance matting designed for high traffic areas.
Set the scene with Gateway 10 (Frontrunner Entry), the ideal low profile integrated matting system for busy entrance areas.
The mat’s unique ‘scrape and clean’ system traps and collects dirt and debris, preventing it from coming inside. This expands the life of your floor finishes and keeps interiors looking stylish for longer.
Whether you’re in need of a surface-mounted or recessed walk-off mat, Gateway fits seamlessly with all well depths and has an ability to contour effortlessly to the subfloor. The mat’s durability makes it the perfect entrance floor mat for any building with medium to high amounts of foot traffic, from retail and hospitality to education and commercial.
Seamless integration
Choose from modules with ramped PVC edging, rolls in standard widths and 10m lengths, or order a custom size
Simple installation
One-piece construction means the entrance matting can be cut to size on site, with no previous site visits needed
Easy to maintain
Simply roll or lift to clean, no special tools needed
Features
Embossed pattern
Two layer, open-grid construction
Close mesh grid
Made from flexible PVC
Comes in 10m (33') rolls or modules
Benefits
Certified slip resistant (DIN 51130: R11, ASTM 1677: 0.6/0.6)
Excellent drainage (DIN 51130: V10)
Wheel and heel proof
Easy to cut on site, contours to uneven surfaces
Seamless installation
| Gateway 10 | Gateway 14 | |
| Height | 10.5mm (13/32") | 14mm (9/16") |
| Standard roll options | 10 x 0.6m (33' x 2') | 10 x 0.6m (33' x 2’) |
| 10 x 0.91m (33' x 3') | 10 x 0.91m (33' x 3’) | |
| 10 x 1.22m (33' x 4') | 10 x 1.22m (33' x 4’) | |
| Standard module options | 0.8 x 1.22m (2'7" x 4’) | |
| 1 x 1.5m (3'3" x 4’11") | ||
| 1.1 x 2m (3'7" x 6’7") | ||
| Weight | 8.7 kg/m2 (1.6 lbs/sq.ft) | 10.5 kg/m2 (2 lbs/sq.ft) |
Surface modules are supplied with factory fitted PVC ramped edging to four sides
| Acoustic | Excellent sound absorption. |
| Chemical | Resistant to most acids, alkalines and oils. You can read more about specific chemical resistances by downloading this information sheet. |
| Composition | Flexible Polyvinyl Chloride (PVC) |
| Environment | Gateway is 100% recyclable. We don’t use any substances included in the SVHC list under REACH in any of our matting products. |
| Reversion | Thermoplastic shrinkage can result in size reductions up to 2%. This may be accelerated in hot environments. You can read more about the causes of shrinkage by downloading this information sheet. |
| Slip resistance | ASTM E303 Dry/Wet with lines along–lines across 74-93 / 48-75 |
| Thermal | Designed to function at temperatures from -23°C and up to +60°C. Slight size variation may occur at temperature extremes. |
| UV light | Resistant to PVC degradation. |
| Volatile organic compound (VOC) | CDPH/EHLB Standard Method V1.2-2017 (California Section 01350) - School Classroom: PASS
CDPH/EHLB Standard Method V1.2-2017 (California Section 01350) - Office: PASS |
| Warranty | Gateway 10: two years. Gateway 14: four years, Visit our policies page for more information about warranties. |
For surface-mounted installations: Gateway 10
Aluminum ramp (H:10mm)
Supplied in sections of 2m (6'6") length , optional Tapcon Concrete Screws are available. Comes in anodized aluminum. Size: 10mm x 45mm x 2m (3/8" x 1 13 /16" x 6'6")
PVC edging (H: 10mm, W: 50mm)
Supplied in rolls of 10.1m (33') length with cold welding paste. Comes in black and dark grey. Size: 10mm x 50mm x 10.1m (3/8" x 2" x 33')
Connector clips: side-to-side (H: 10mm)
For joining sections of low profile matting together side-to-side. Supplied in packs of 10
PVC snap track (H: 10.5mm)
Two-part snap track that can be welded together to join rolls end-to-end or side-to-side to cover large areas. Supplied with cold welding paste. Comes in dark grey. Size: 10.5mm x 2.5m (13/32" x 8'2")
For recessed installations: Gateway 10
Aluminum mat divider (H:10mm)
If the front-to-back dimension of the mat well is greater than the final width of your matting, you may need an aluminum mat divider to secure the different sections together. Mat dividers can also be used to divide the overall vestibule into smaller sections, or as a perimeter frame in recessed applications. Supplied in sections of 3m (10') length. Optional “spike” concrete anchors are available. Comes in aluminum. Size: 10mm x 18mm x 3m (3/8" x 11/16" x 10’)
R frame (H: 10mm)
You'll need these to secure the matting on the left-to-right edges. Supplied in sections of 3m (10') length with fixing screws and plugs. Comes in anodised aluminium, powder coated dark grey and black. Size: 10mm x 12mm (3/8" x 15/32")
Z frame (H: 10mm)
Installing matting next to ceramic tiles? You'll need a Z frame to secure the matting. Supplied in sections of 3.6m (12') length with fixing screws and plugs. Comes in anodised aluminium. Size: 10mm x 24mm (3/8" x 15/16")
H section (H: 10mm)
If the front-to-back dimension of the mat well is greater than the final width of your matting, you may need a H section to secure the different sections together. Supplied in sections of 12' (3.6m) length, with fixing screws and plugs. Comes in black, with mat insert colour specified. Size: 3/8" x 1/2" (10mm x 13mm).
For surface-mounted installations: Gateway 14
PVC edging (H: 14mm, W: 60mm)
Supplied in rolls of 10.1m (33') length with cold welding paste. Comes in black, dark grey, dark brown, holly green, Oxford blue, yellow. Size: 14mm x 60mm x 10.1m (9/16" x 2 1/2" x 33')
PVC edging (H: 14mm, W: 100mm)
Supplied in rolls of 10.1m (33') length with cold welding paste. Comes in black, dark grey and yellow. Size: 14mm x 100mm x 10.1m (9/16" x 3 3/4" x 33')
Aluminium edging (H: 15mm)
Supplied in sections of 2m (6'6") length with fixing screws and plugs. Comes in anodised aluminium and powder coated yellow. Size: 15mm x 45mm x 2m (9/16" x 1 13 /16" x 6'6")
Connector clips: side-to-side (H: 14mm)
For joining sections of matting together side-to-side. Supplied in packs of 10
PVC snap track (H: 14mm)
Two-part snap track that can be welded together to join rolls end-to-end or side-to-side to cover large areas. Supplied with cold welding paste. Comes in black and dark grey. Size: 14mm x 2.5m (9/16" x 8'2")
For recessed installations: Gateway 14
R frame (H: 14mm)
You'll need these to secure the matting on the left-to-right edges. Supplied in sections of 3m (10') length with fixing screws and plugs. Comes in anodised aluminium, powder coated dark grey and black. Size: 14mm x 12mm (9/16" x 15/32")
H section (H: 14mm)
If the front-to-back dimension of the mat well is greater than the final width of your matting, you may need a H section to secure the different sections together. Supplied in sections of 12' (3.6m) length, with fixing screws and plugs. Comes in black, with mat insert colour specified. Size: 9/16" x 1/2" (14mm x 13mm)
J frame (H: 18mm)
Installing Gateway against a wall? You'll need a J frame to secure the matting on the left-to-right edges. Supplied in sections of 3m (10') length. Comes in dark grey and black. Size: 18mm x 60mm (11/16" x 2 3/8")
T frame (H: 14mm)
You can use a T frame (27mm) to divide the matting into sections left-to-right – this makes it easier to lift and clean. Supplied in sections of 3m (10') length with fixing screws and plugs. Comes in anodised aluminium, powder coated dark grey and black
TL frame (H: 14mm)
You can use a T/L frame (55mm) to divide the matting into sections left-to-right – this makes it easier to lift and clean. Supplied in sections of 3m (10') length with fixing screws and plugs. Comes in anodised aluminium
L frame (H: 15mm)
Installing around a circular door or non rectangular space? You'll need a L frame to secure the matting. Size: 15mm x 2.7m length (5/8" x 8')
U section (H: 14mm)
If the front-to-back dimension of the mat well is greater than the final width of your matting, you may need a U section to secure the different sections together. Supplied in sections of 3m (10') length, with fixing screws and plugs. Comes in anodised aluminium, powder coated dark grey and black. Size: 14mm x 19mm (9/16" x 3/4")
Gateway 10's one-piece construction means installation is simple
- Integrates seamlessly with all internal floor coverings
- Fits with different well depths
- Contours to the floor
- Cut to fit on site – no special tools or previous site visits needed
Watch the videos below for step-by-step installation guides, or download the recessed entrance matting installation instructions and the surface-mounted installation instructions.
Keeping Gateway 10 looking good is easy
- Simply roll or lift to clean
- No special tools needed
- Easy to clean using a vacuum, plus a coarse brush for clearing the debris in the grid
Watch our step-by-step guide to daily, weekly and monthly cleaning below, or download the instructions.
Download our BIM objects in both Revit and IFC file types
Features
Embossed pattern
Two layer, open-grid construction
Close mesh grid
Made from flexible PVC
Comes in 10m (33') rolls or modules
Benefits
Certified slip resistant (DIN 51130: R11, ASTM 1677: 0.6/0.6)
Excellent drainage (DIN 51130: V10)
Wheel and heel proof
Easy to cut on site, contours to uneven surfaces
Seamless installation
| Gateway 10 | Gateway 14 | |
| Height | 10.5mm (13/32") | 14mm (9/16") |
| Standard roll options | 10 x 0.6m (33' x 2') | 10 x 0.6m (33' x 2’) |
| 10 x 0.91m (33' x 3') | 10 x 0.91m (33' x 3’) | |
| 10 x 1.22m (33' x 4') | 10 x 1.22m (33' x 4’) | |
| Standard module options | 0.8 x 1.22m (2'7" x 4’) | |
| 1 x 1.5m (3'3" x 4’11") | ||
| 1.1 x 2m (3'7" x 6’7") | ||
| Weight | 8.7 kg/m2 (1.6 lbs/sq.ft) | 10.5 kg/m2 (2 lbs/sq.ft) |
Surface modules are supplied with factory fitted PVC ramped edging to four sides
| Acoustic | Excellent sound absorption. |
| Chemical | Resistant to most acids, alkalines and oils. You can read more about specific chemical resistances by downloading this information sheet. |
| Composition | Flexible Polyvinyl Chloride (PVC) |
| Environment | Gateway is 100% recyclable. We don’t use any substances included in the SVHC list under REACH in any of our matting products. |
| Reversion | Thermoplastic shrinkage can result in size reductions up to 2%. This may be accelerated in hot environments. You can read more about the causes of shrinkage by downloading this information sheet. |
| Slip resistance | ASTM E303 Dry/Wet with lines along–lines across 74-93 / 48-75 |
| Thermal | Designed to function at temperatures from -23°C and up to +60°C. Slight size variation may occur at temperature extremes. |
| UV light | Resistant to PVC degradation. |
| Volatile organic compound (VOC) | CDPH/EHLB Standard Method V1.2-2017 (California Section 01350) - School Classroom: PASS
CDPH/EHLB Standard Method V1.2-2017 (California Section 01350) - Office: PASS |
| Warranty | Gateway 10: two years. Gateway 14: four years, Visit our policies page for more information about warranties. |
For surface-mounted installations: Gateway 10
Aluminum ramp (H:10mm)
Supplied in sections of 2m (6'6") length , optional Tapcon Concrete Screws are available. Comes in anodized aluminum. Size: 10mm x 45mm x 2m (3/8" x 1 13 /16" x 6'6")
PVC edging (H: 10mm, W: 50mm)
Supplied in rolls of 10.1m (33') length with cold welding paste. Comes in black and dark grey. Size: 10mm x 50mm x 10.1m (3/8" x 2" x 33')
Connector clips: side-to-side (H: 10mm)
For joining sections of low profile matting together side-to-side. Supplied in packs of 10
PVC snap track (H: 10.5mm)
Two-part snap track that can be welded together to join rolls end-to-end or side-to-side to cover large areas. Supplied with cold welding paste. Comes in dark grey. Size: 10.5mm x 2.5m (13/32" x 8'2")
For recessed installations: Gateway 10
Aluminum mat divider (H:10mm)
If the front-to-back dimension of the mat well is greater than the final width of your matting, you may need an aluminum mat divider to secure the different sections together. Mat dividers can also be used to divide the overall vestibule into smaller sections, or as a perimeter frame in recessed applications. Supplied in sections of 3m (10') length. Optional “spike” concrete anchors are available. Comes in aluminum. Size: 10mm x 18mm x 3m (3/8" x 11/16" x 10’)
R frame (H: 10mm)
You'll need these to secure the matting on the left-to-right edges. Supplied in sections of 3m (10') length with fixing screws and plugs. Comes in anodised aluminium, powder coated dark grey and black. Size: 10mm x 12mm (3/8" x 15/32")
Z frame (H: 10mm)
Installing matting next to ceramic tiles? You'll need a Z frame to secure the matting. Supplied in sections of 3.6m (12') length with fixing screws and plugs. Comes in anodised aluminium. Size: 10mm x 24mm (3/8" x 15/16")
H section (H: 10mm)
If the front-to-back dimension of the mat well is greater than the final width of your matting, you may need a H section to secure the different sections together. Supplied in sections of 12' (3.6m) length, with fixing screws and plugs. Comes in black, with mat insert colour specified. Size: 3/8" x 1/2" (10mm x 13mm).
For surface-mounted installations: Gateway 14
PVC edging (H: 14mm, W: 60mm)
Supplied in rolls of 10.1m (33') length with cold welding paste. Comes in black, dark grey, dark brown, holly green, Oxford blue, yellow. Size: 14mm x 60mm x 10.1m (9/16" x 2 1/2" x 33')
PVC edging (H: 14mm, W: 100mm)
Supplied in rolls of 10.1m (33') length with cold welding paste. Comes in black, dark grey and yellow. Size: 14mm x 100mm x 10.1m (9/16" x 3 3/4" x 33')
Aluminium edging (H: 15mm)
Supplied in sections of 2m (6'6") length with fixing screws and plugs. Comes in anodised aluminium and powder coated yellow. Size: 15mm x 45mm x 2m (9/16" x 1 13 /16" x 6'6")
Connector clips: side-to-side (H: 14mm)
For joining sections of matting together side-to-side. Supplied in packs of 10
PVC snap track (H: 14mm)
Two-part snap track that can be welded together to join rolls end-to-end or side-to-side to cover large areas. Supplied with cold welding paste. Comes in black and dark grey. Size: 14mm x 2.5m (9/16" x 8'2")
For recessed installations: Gateway 14
R frame (H: 14mm)
You'll need these to secure the matting on the left-to-right edges. Supplied in sections of 3m (10') length with fixing screws and plugs. Comes in anodised aluminium, powder coated dark grey and black. Size: 14mm x 12mm (9/16" x 15/32")
H section (H: 14mm)
If the front-to-back dimension of the mat well is greater than the final width of your matting, you may need a H section to secure the different sections together. Supplied in sections of 12' (3.6m) length, with fixing screws and plugs. Comes in black, with mat insert colour specified. Size: 9/16" x 1/2" (14mm x 13mm)
J frame (H: 18mm)
Installing Gateway against a wall? You'll need a J frame to secure the matting on the left-to-right edges. Supplied in sections of 3m (10') length. Comes in dark grey and black. Size: 18mm x 60mm (11/16" x 2 3/8")
T frame (H: 14mm)
You can use a T frame (27mm) to divide the matting into sections left-to-right – this makes it easier to lift and clean. Supplied in sections of 3m (10') length with fixing screws and plugs. Comes in anodised aluminium, powder coated dark grey and black
TL frame (H: 14mm)
You can use a T/L frame (55mm) to divide the matting into sections left-to-right – this makes it easier to lift and clean. Supplied in sections of 3m (10') length with fixing screws and plugs. Comes in anodised aluminium
L frame (H: 15mm)
Installing around a circular door or non rectangular space? You'll need a L frame to secure the matting. Size: 15mm x 2.7m length (5/8" x 8')
U section (H: 14mm)
If the front-to-back dimension of the mat well is greater than the final width of your matting, you may need a U section to secure the different sections together. Supplied in sections of 3m (10') length, with fixing screws and plugs. Comes in anodised aluminium, powder coated dark grey and black. Size: 14mm x 19mm (9/16" x 3/4")
Gateway 10's one-piece construction means installation is simple
- Integrates seamlessly with all internal floor coverings
- Fits with different well depths
- Contours to the floor
- Cut to fit on site – no special tools or previous site visits needed
Watch the videos below for step-by-step installation guides, or download the recessed entrance matting installation instructions and the surface-mounted installation instructions.
Keeping Gateway 10 looking good is easy
- Simply roll or lift to clean
- No special tools needed
- Easy to clean using a vacuum, plus a coarse brush for clearing the debris in the grid
Watch our step-by-step guide to daily, weekly and monthly cleaning below, or download the instructions.
Download our BIM objects in both Revit and IFC file types
